Dual Set Point Pressure Switch ( Flameproof)
Product Details:
| Minimum Order Quantity | 1 Piece |
| Protection Type | Increased Safety Ex e |
| Area Classification | Zone 2 |
| Gas Group | IIB |
| Material to Measure | Gas |
| Switch Function | Changeover |
| Rated Voltage | 230 V AC |
| Contact Configuration | 1NC |
| Ingress Protection | IP54 |
| Cable Entry | M20 |
| Brand | Smart Tech |
Product and Description: Flame proof pressure switch Exd IP67
Range: 2 Pressure Range (Internal Range setting mechanism)
Sensing Elements: Piston operated Diaphragm SS316L
Wetted Part: SS 316
Enclosure: Exd IIA IIB Certified as per IS/IEC60079-0:2004 & IS/IEC60079-1:2007
Protection : IP67
Enclosure: Die cast Aluminum
Micro switch – 1 SPDT X 2 Contact (1 for Each pressure Switch)
Electrical rating: 5A 250V AC ,
Repeatability: + – 1% of FS
Accuracy: +-1% of FS
Working Temp: 150 Deg C
Proof Pressure : 150% of FS
Differential : Fixed Type
Process Connection: 1/4″ NPT(F) X 1
Cable entry: 3/4″ ET OR M20 X 1.5P OR ½” NPTX 2
PRESSURE RANGE UP TO 40 BAR
